DEFENCE ADHESIVE SPEEDY
New
文件
技术数据表
|
|---|
DEFENCE ADHESIVE SPEEDY
| CODE | description | liner | H
[m]
|
L
[m]
|
A
[m²]
|
H
[ft]
|
L
[ft]
|
A
[sft]
|
pcs./pallet |
|---|---|---|---|---|---|---|---|---|---|
| DEFASPEEDY | - | no liner | 1.55 | 50 | 77.5 | 5' 1'' | 164 | 834 | - |
| DEFASPEEDY385 | - | - | 0.385 | 50 | 19.25 | - | 164 | 207 | - |
| DEFASPEEDY490 | - | - | 0.49 | 50 | 24.5 | - | 164 | 264 | - |
技术数据
| 属性 | 标准 | 数值经过测试 | USC 转换 |
|---|---|---|---|
| Mass per unit area | EN 1849-2 | 220 g/m² | 0.72 oz/ft² |
| Thickness | EN 1849-2 | 0,3 mm | 12 mil |
| Water vapour transmission (Sd) | EN 1931 | 3,5 m | 0.999 US perm |
| Tensile strength MD/CD | EN 12311-2 | > 120 / 80 N/50mm | > 14 / 9 lbf/in |
| Resistance to nail tearing MD/CD | EN 12310-1 | > 60 / 65 N | > 13 / 15 lbf |
| Watertightness | EN 1928 | compliant | - |
| Resistance to temperature | - | -40 / 80 °C | -40 / 176 °F |
| Reaction to fire | EN 13501-1 | class E | - |
| Resistance to penetration of air | EN 12114 | < 0,02 m³/(m²·h·50Pa) | < 0.001 cfm/ft² at 50Pa |
| Density | - | ca. 740 kg/m³ | - |
| Water vapour resistance factor (μ) | - | ca. 11600 | - |
| UV stability | - | 336h (3 months) | - |
| Exposure to weather | - | 12 weeks | - |
| Elongation MD/CD | EN 12311-1 | > 40 / 40 % | - |
| Flexibility at low temperatures | EN 1109 | -40 °C | -40 °F |
| Adhesion strength on OSB at 180° after 10 minutes | EN ISO 29862 | 2 N/10mm | 1.1 lbf/in |
| Adhesion strength on OSB at 90° after 10 minutes | EN ISO 29862 | 2 N/10mm | 1.1 lbf/in |
| Forza di adesione a taglio del sormonto dopo 24 ore | EN 12317-2 | 80 N/50mm | 9.1 lbf/in |
| Storage temperature | - | -5 / 35 °C | 23 / 95 °F |
| Application temperature | - | 5 / 25 °C | 41 / 77 °F |
| Solvents | - | no | - |
成分
| TOP LAYER | EVA functional film |
|---|---|
| BOTTOM LAYER | non-woven PP fabric |
| GLUE | acrylic dispersion without solvents |
